Y15
1000 W Hub Motor
Up To 60 km/h
Description
Contact Us
Please take a moment to fill out the form. we will get back to you ASAP.
Technical Parameters
| Dimensions (mm): | 1740 × 700 × 1100 |
| Carton Dimensions (mm): | 1600 × 400 × 850 |
| Wheelbase (mm): | 1245 |
| Seat Height (mm): | 750 |
| Ground Clearance (mm): | 130 |
| Curb Weight (kg; excl. battery): | 65 |
| Max. Load (kg): | 150 |
| Max. Speed (km/h): | 60 |
| Range (by battery): | Lead-acid 40 / 55 / 70 km; lithium 60–200 km |
| Motor / Rated Power: | 1000 W Hub motor |
| Battery Options: | 48 / 60 / 72 V; 20–40 Ah; lead-acid / lithium |
| Charger (72 V option): | 72 V / 2.5–3 A |
| Charging Time: | 6–8 h |
| Climbing Angle: | ≤15° |
| Frame: | Truss-type steel tube |
| Suspension: | Front: Ø27 oil-damped; rear: dual oil-damped |
| Front / Rear Tires: | 3.0-10 tubeless |
| Brakes: | Front 200 mm disc; rear 110 mm drum |
| Instrument: | Digital display |
| Lighting: | LED headlight, tail light & turn signals |
*The specs is only for your reference. The specifications may be subject to change due to local laws and regulations in different countries and regions.
